Stainless steel 316/316L
Material type: Metal, Corrosion resistant, Chemical resistant, High strength, Heat resistant, Non-magnetic
The second most used stainless steel after 304, the general purpose austenitic stainless steel 316 has superior corrosion resistance particularly in chloride containing environments and good elevated temperature strength. The low carbon version 316L has even better corrosion resistance in welded structures.
Process compatibility
Material Color
Material advantages
SUS316 stainless steel has good plasticity, toughness, cold denaturation, and welding process performance. 316 has good high temperature strength, and 316L has poor high temperature performance, but its corrosion resistance is better than 316.
Material shortcomings
Recommended description
Stainless steel 316/316L has similar mechanical properties to 304, with higher corrosion and chemical resistance. Ideal for marine applications.
Tensile strength 620 MPa
Yield strength 310 MPa
Density 8g/cm3
Modulus of elasticity 205 GPa
Elongation at break 30% - 50%
Hardness 83 HRB
Maximum working temperature 925 °C
Thermal conductivity 17 W/(m⋅°C)
Electrical resistivity 81 μΩ*cm
Common applications
• Food preparation equipment particularly in chloride environments.
• Laboratory benches & equipment.
• Coastal architectural panelling, railings & trim.
• Boat fittings
• Chemical containers, including for transport.
• Heat exchangers
• Woven or welded screens for mining, quarrying & water filtration.
• Threaded fasteners
• Springs
