Flex & Rigid-Flex PCBs Manufacturing Capabilities

PCBWay provides fully customizable flex & rigid-flex circuit boards, allowing clients to select the number of layers, thickness, materials, and surface finishes, ensuring that even the most complex designs can be accommodated with ease and precision.

Flexible PCB

Flexible PCB

Rigid-Flex PCB

Rigid-Flex PCB

Feature Capability
Layer 1-12
Board thickness (without stiffener) 4‐40 mil
Tolerance of single layer ±1.0mil
Tolerance of double‐layer (≤12mil) ±1.2 mil
Tolerance of multi‐layer (≤12mil) ±1.2 mil
Tolerance of multi‐layer (12mil‐32mil) ±8%
Tolerance of board thickness (including PI stiffener) ±10%
Min. board size 0.0788” *0.1576” (without bridge) 0.3152” * 0.3152” (with bridge)
Max. board size 8.668” * 27.5”
Impedance control tolerance ±4Ω (≤50Ω), ±7% (>50Ω)
Min. coverlay bridge 8 mil
Min. bend radius of single layer 3‐6 times of board thickness
Min. bend radius of double‐layer 7‐10 times of board thickness
Min. bend radius of multi‐layer 10‐15 times of board thickness
Min. mechanical drill hole 4 mil
Inner Layer Trace/ Space 2/ 2 mil
Outer Layer Trace/ Space 2/ 2 mil
Solder mask color Green\Black
Surface treatment HASL, ENIG, ENEPIG, Electrolytic Nickel Gold, Soft gold, Hard gold, Immersion silver and OSP, Immersion tin
Laser accuracy (Routing) ±2 mil
Punching accuracy (Routing) ±2 mil ‐ ±6 mil
Feature Capability
Layer 26L
Min. Track/Spacing 0.065 mm/0.065 mm
Min. Hole/pa Size 0.10/0.35 mm
Rigid-Flex Thickness 0.25-6.0mm
MAX CU Thickness 4 OZ
Drilling accuracy +/-0.05 mm
PTH diameter tolerance +/-0.05 mm
MAX WPNL SIZE 620 mm × 500 mm
Finish Copper (Flex Part) 0.5-2oz
Finish Copper (Rigid Part) 1-4oz
Surface treatment ENIG, Electric gold, IM-Ag, Electric Ag, HASL, HASL-LF, IM-Sn, Electric Sn, OSP, Caborn, Pt, NI-Pd-AU
Max board thickness: PTH diameter 13:1
Build time 7-20 days
RFQ 1-2 days

Featured Product Solutions

Flex and rigid-flex PCBs are widely used across various industries due to their unique combination of flexibility, durability, and design versatility. Applications include wearable devices, medical equipment, aerospace and defense systems, automotive systems, consumer electronics, industrial automation, and telecommunications.
