PCB Production standards follow IPC Class 2,IPC Class 3, ,Automotive Standard, Customer Standard
|Item||Advanced PCB||Standard PCB|
one file/1 days+
|Shengyi,Rogers,Arlon,Isola, Omega,Nelco,3M etc.Meet IPC4101 class B/L||KB(kingboard)/GDM(goldenmax) Meet IPC4101 class B/L|
|Rohm&Haas,TAIYO,Kuangshun,Meet IPC-SM-840 class T||TAIYO,Kuangshun,Meet IPC-SM-840 class T|
|Drilling||Min Mechanical Hole Size 0.15mm,Laser hole 0.1mm||Min Mechanical Hole Size 0.2mm|
|Plating||PTH (Hole copper thickness≥20um),IPC 3(25um)||PTH（Hole copper thickness≥18um）|
|Test method||A.O.I,Kelvin Four-terminal sensing,Microsection Inspection,Solderability Test,Impedance Test...||A.O.I.,Fly Probe Testing, E-test fixture|
|Glass transition ℃||>140℃||>130℃|
|Etched line||Forbid to repair tracks(IPC 3,Automotive,Customer Standard)||-|
|Cleanliness||Cleanliness requirements beyond those of IPC||Cleanliness requirements beyond those of IPC|
Tolerances will be controlled into +/-0.2 mm(+/-0.01") in accordance with ISO 2768. For other tighter tolerances, technical drawing will be required to indicate critical dimensions.
|Limits for nominal size||
Coarse class (c)
Medium class (m)
|0.5mm* to 3mm||±0.2mm||±0.1mm|
|3mm to 6mm||±0.3mm||±0.1mm|
|6mm to 30mm||±0.5mm||±0.2mm|
|30mm to 120mm||±0.8mm||±0.3mm|
|120mm to 400mm||±1.2mm||±0.5mm|
|400mm to 1000mm||±2.0mm||±0.8mm|
|1000mm to 2000mm||±3.0mm||±1.2mm|
|2000mm to 4000mm||±4.0mm||±2.0mm|
|SLS||L<100mm,±0.25mm. 100< L<200mm,±0.3mm 200< L<500mm,±0.5mm. L>500mm,±0.1%*L(mm)|
The perfect quality assurance system and various testing equipment help us monitor the entire production process to ensure the stability of the process and product quality. At the same time, we also introduce advanced instruments and technical methods to achieve continuous improvement.
For each order submitted, Gerber files will be reviewed by our professional engineers before being sent to production. Engineers will confirm the production feasibility in terms of tolerance constraints such as board edge clearance, drilling, pad spacing, impedance and routing. When the engineer finds a problem with the file or there is something that can be optimized, an EQ will be raised, and our customer service representative will get in touch with you, so as not to delay production.
The quality of the raw materials determines durability of the finished products. Ensuring the high quality of raw materials is one of the most basic principles for PCBWay to manufacture products. PCBWay has been working with leading suppliers in the industry,and inspect materials according to international standards and customer requirements, such as Shengyi, Rogers, KB (kingboard) sheet, Rohm&Haas, TAIYO high-performance solder mask ink.Click to view raw materials
In order to ensure the best quality and reliability of PCB products, PCBWay continuously introduces advanced equipment, including but not limited to the following:
We strictly comply with ISO9001:2015 requirements and all production processes are in
line with IPC standards. In addition to basic visual inspections, all boards undergo the
most rigorous electrical tests. We use industry-renowned testing and inspection
equipment such as Flying Probe Testing, AOI (Automated Optical Inspection) and Copper
We guarantee that every PCB in your hand is in good condition and you can proceed to the next step of assembly safely. Various types of test reports are available upon request.
After lamination, there will be slicing test (to confirm the thickness of the dielectric), thermal shock test (to confirm whether it is delaminated), and also copper foil adhesion test.
We will control the service life of the drill tips. The drill tips are coated, which can prolong the service life and reduce the hole diameter. After drilling, there is a test for roughness of hole side, and drilling machine inspection to check the hole position, aperture, whether there is missing hole or plug hole, etc.
Backlight test is performed after plating process to check the thickness for plated copper.
CMI700 will be used to check the surface copper and hole wall copper. We normally use a small current for electroplating to ensure the even copper thickness.
In this process, the engineer will check the width and spacing of the circuits for the first piece, and later perform another random check. There is a checking station for the developing process to ensure the good quality.
AOI is performed after pattern plating. It is an automated optical inspection of PCBs in which a camera is used to scan the circuit board in extremely fine detail to check for any defects or malfunctions.
We use LDI,automatic alignment exposure machine, to finish high quality soldermask process. Solder mask and silkscreen have to also go through QC semi-inspection, and there is also QA inspection (spot check) to check whether the solder mask is not fully developed, whether the solder mask enters the hole, whether the silkscreen printing is qualified, and whether the ink is too much to cause thick characters, etc.
Flying probe test and fixture test are typically performed at this stage
Now the boards will go through the routing process twice, and the second time is the fine routing.
First sample inspection is needed after going through V-cut process.
After the FQC inspection, there are also FQA random inspections, solder mask 3M adhesion tests, slicing test, and solderability test.
The role of the physical laboratory is to use some devices to make quality tests on the boards of related processes. Commonly used tests include: metallographic microscope, X-ray inspection of inner layer, X-ray test of gold thickness, impedance tester, peel strength tester, coil resistance test, quadratic element, copper thickness tester, solderability test, backlight test, particle contamination test, soldermask 3M adhesion test, copper thickness test,etc.
The chemical laboratory generally checks the correct ratio of chemical ingredients to ensure the quality of the boards. Usually, some processes that need to use potions are inspected, including: copper plating, electroplating, solder mask, etching, developing, lamination of brown lines, surface treatment, etc.
Our quality control systems are regularly audited and assessed to ensure their compliance and effectiveness. A complete quality control system and 100% PCB testing procedures will ensure that every order you entrust is completed perfectly.
