5G signal test PCB board, this type of circuit board is made of RO4350B+TU768 material, produced by mixed pressure, mechanical drilling, surface immersion gold and other processes, the smallest aperture can reach 0.2mm, the Min Track/Spacing can reach 100/100um . The PCB circuit board is widely used in the field of 5G signal testing.
4 layers, Thickness: 1.12mm, Surface Finish: HASL lead free
2 layers, Thickness: 1.2mm
2 layers, Thickness: 1.6mm, Surface Finish: Immersion gold(ENIG)
6 layers, Thickness: 1.6mm, Surface Finish: Immersion gold(ENIG)
6 layers, Thickness: 2.6mm, Size: 6*6cm
10 layers, Material: FR4, Thickness: 1.6mm
6 layers, Thickness: 1.0mm, Surface Finish: Immersion gold(ENIG) 3U"
12 layers, Material: FR4, Thickness: 1.6mm
4 layers, Thickness: 0.8mm, Surface Finish: Immersion gold(ENIG)
6 layers, Thickness: 1.6mm, Surface Finish: Immersion gold(ENIG)
8 layers, Material: S1000-2M, Thickness: 1.0±0.1mm
12 layers, Material: S1000-2M, Thickness: 1.2±0.1mm
